Valves
BRONZE Y – STRAINER ( BSPT ENDS )
Materials
Parts Material Body Bronze Body cap Brass Screen type 304 stainless steel A B 1/2to 2 Height 1.4 2.4 Dimensions
Nominal Size inch 1/2 3/4 1 1 1/4 1 1/2 2 DN 15 20 25 32 40 50 L Threaded end to end 80 100 115 135 160 195 H Height 49 57 70 82 98 121 H1 68 83 105 124 149 188 SKU: n/a -
-
ABB, Electrical Products
FH204 AC-40/0,3 – 40A 4P ELCB 300MA
Ensure safety with the FH204 AC-40/0.3 Residual Current Circuit Breaker. This 4-pole Type AC device provides reliable protection with a sensitivity of 300 mA. Ideal for industrial and commercial applications, it automatically disconnects the circuit upon detecting residual currents, preventing electrical hazards. Designed for robust performance and easy installation, it meets international standards for quality and safety.
SKU: 2CSF204006R3400 -
Valves
BRONZE GLOBE ( BSPT ENDS )
Materials
Parts Material Body Bronze Bonnet Brass Stem Dezincification Resistant Brass Disc Bronze Gland Packing Aramid Fibers Graphite Dimensions
Nominal Size inch 1/2 3/4 1 1 1/4 1 1/2 2 DN 15 20 25 32 40 50 L Threaded end to end 53 65 77 85 100 119 H Height, valve open 79 93 104 127 145 174 D Handwheel diam 60 70 80 90 100 115 SKU: n/a -
-
Valves
PN16 BRONZE GATE VALVE
Materials
Parts Material Body Brass Bonnet Brass Stem Dezincification Resistant Brass Disc Brass Gland Packing Aramid Fibers Graphite Dimensions
Nominal Size inch 1/2 3/4 1 1 1/4 1 1/2 2 DN 15 20 25 32 40 50 L Threaded end to end 42 47 50 60 63 72 H Height, valve open 73 87 97 118 126 154 D Handwheel diam 50 55 60 70 80 90 SKU: KITZ FIG 16FCW -
-
-
Valves
TYPE 600 BRASS BALL VALVE, FULL PORT
Materials
Parts Material Body Brass/Bronze* Body cap Brass/Bronze* Stem Brass: Nickel plated* Ball Brass: chrome free plated (Size 1/4 to 3)
Brass: chrome plated (Size 4)Ball seat PTFE O-ring FKM Dimensions
Nominal Size inch 1/4 3/8 1/2 3/4 1 1 1/4 1 1/2 2 2 1/2 3 4 mm 8 10 15 20 25 32 40 50 65 80 100 L Threaded end to end 42 42 53 60 72 84 92 110 138 167 193 L1Solder – 46 54 73 88 100 115 140 164 187 – H Height 37 37 40 43 50 55 65 72 100 112 131 H1Solder – 37 40 44 50 55 65 72 100 112 – DLength of Handle 70 70 80 80 110 110 150 150 200 300 300 SKU: n/a -
-
ABB, Electrical Products
FH204 AC-40/0,3 – 40A 4P ELCB 300MA
Ensure safety with the FH204 AC-40/0.3 Residual Current Circuit Breaker. This 4-pole Type AC device provides reliable protection with a sensitivity of 300 mA. Ideal for industrial and commercial applications, it automatically disconnects the circuit upon detecting residual currents, preventing electrical hazards. Designed for robust performance and easy installation, it meets international standards for quality and safety.
SKU: 2CSF204006R3400 -
-
-
-
ABB, Electrical Products
FH204 AC-40/0,3 – 40A 4P ELCB 300MA
Ensure safety with the FH204 AC-40/0.3 Residual Current Circuit Breaker. This 4-pole Type AC device provides reliable protection with a sensitivity of 300 mA. Ideal for industrial and commercial applications, it automatically disconnects the circuit upon detecting residual currents, preventing electrical hazards. Designed for robust performance and easy installation, it meets international standards for quality and safety.
SKU: 2CSF204006R3400 -
-
Valves
BRONZE GLOBE ( BSPT ENDS )
Materials
Parts Material Body Bronze Bonnet Brass Stem Dezincification Resistant Brass Disc Bronze Gland Packing Aramid Fibers Graphite Dimensions
Nominal Size inch 1/2 3/4 1 1 1/4 1 1/2 2 DN 15 20 25 32 40 50 L Threaded end to end 53 65 77 85 100 119 H Height, valve open 79 93 104 127 145 174 D Handwheel diam 60 70 80 90 100 115 SKU: n/a -
Valves
PN16 BRONZE GATE VALVE
Materials
Parts Material Body Brass Bonnet Brass Stem Dezincification Resistant Brass Disc Brass Gland Packing Aramid Fibers Graphite Dimensions
Nominal Size inch 1/2 3/4 1 1 1/4 1 1/2 2 DN 15 20 25 32 40 50 L Threaded end to end 42 47 50 60 63 72 H Height, valve open 73 87 97 118 126 154 D Handwheel diam 50 55 60 70 80 90 SKU: KITZ FIG 16FCW -
-
-
Valves
TYPE 600 BRASS BALL VALVE, FULL PORT
Materials
Parts Material Body Brass/Bronze* Body cap Brass/Bronze* Stem Brass: Nickel plated* Ball Brass: chrome free plated (Size 1/4 to 3)
Brass: chrome plated (Size 4)Ball seat PTFE O-ring FKM Dimensions
Nominal Size inch 1/4 3/8 1/2 3/4 1 1 1/4 1 1/2 2 2 1/2 3 4 mm 8 10 15 20 25 32 40 50 65 80 100 L Threaded end to end 42 42 53 60 72 84 92 110 138 167 193 L1Solder – 46 54 73 88 100 115 140 164 187 – H Height 37 37 40 43 50 55 65 72 100 112 131 H1Solder – 37 40 44 50 55 65 72 100 112 – DLength of Handle 70 70 80 80 110 110 150 150 200 300 300 SKU: n/a -
